Shervey Flush Starlink Mini Mount

Product Overview

• The Shervey Flush Starlink Mini Mount is designed for permanent installation of the Starlink Mini antenna onto vehicle roof racks, fleet platforms and fixed structures where a compact, refined and secure mounting solution is required.
• The enclosure provides a rigid mounting interface while maintaining a streamlined profile to reduce wind exposure and minimise visual impact. The flush acrylic lid design assists with water shedding while protecting the antenna from debris and environmental exposure.
• Manufactured from CNC laser cut and formed aluminium and finished with a corrosion resistant pre-treatment and powder coated finish, the mount is designed for reliable operation in harsh outdoor environments. An optional in-mount weatherproof voltage booster can be supplied pre-installed to simplify electrical integration where 12V supply systems are used.

Features

• Flush lid enclosure design
• Designed specifically for Starlink Mini antenna
• CNC laser cut and formed aluminium construction
• Compatible with major roof rack systems
• Suitable for magnetic mounting systems using threaded magnetic bases
• External Anderson plug input for side cable access
• Cable pass-through provision in base
• 4mm acrylic cover providing mechanical protection
• Internal silicone cover to reduce vibration between mount and antenna
• Secured using M8 stainless steel security fasteners
• Security fastener installation tool included
• Optional in-mount weatherproof voltage booster available
• Suitable for permanent or semi-permanent mounting
• Corrosion resistant pre-treatment and powder coated finish
• Australian designed and manufactured

Specifications

• Compatibility: Starlink Mini
• External dimensions: 396.1 mm (L) x 282.4 mm (W) x 56.4 mm (H)
• Material: CNC formed aluminium
• Construction thickness: 3 mm aluminium body
• Cover material: 4 mm UV-stable acrylic
• Enclosure design: Flush lid enclosure
• Mounting base: Multi-slot mounting pattern
• Mounting compatibility: M8 and M6 fastener systems
• Suitable for magnetic mounting systems using threaded magnetic bases
• Fasteners: M8 stainless steel security fasteners
• Tooling: Security fastener tool included
• Power input: External Anderson plug (side access)
• Cable routing: Base pass-through cable entry
• Vibration isolation: Internal silicone interface cover included
• Voltage booster: Optional in-mount weatherproof 12V to 30V step-up converter
• Finish: Powder coated – Satin Black or White
• Installation type: Permanent or semi-permanent mounting
• Operating environment: External vehicle and fixed installations
• Country of manufacture: Australia
